features:
Input:1*HD MI
Output:1*SDI
Input/Outputresolution:480i,576i,720p50/60,1080p24/25/30,1080i50/60,1080p50/60
Power supply: DC5V
Power Consumption (Max):5W
Dimension: 80mm x 41mm x 25 mm
Weight: 150g
Auto video mode detection(3G/HD/SD).
Connect with other units(SDI to HD MI) to extend your signal over long distances.
SDI interface operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s.
Supports signal transmission distances up to 300M for SD signals, 200 for HD signal and 100M for 3G signal.
