HDMI to HDMI+Audio
Features
*One HDMI signal input is converted into HDMI+Audio (SPDIF+R/L) output *Support audio output: SPDIF+analog R/L *Input supports up to 2160P@30Hz *Audio synchronization and separation output can be achieved, with three audio modes of PASS, 20CH, and 5.1CH to choose from *LED indicator, when the signal source or signal end is in working state, the corresponding indicator will light up *No signal loss *Easy to install *External power supply: DC5V
*One HDMI signal input is converted into HDMI+Audio (SPDIF+R/L) output *Support audio output: SPDIF+analog R/L *Input supports up to 2160P@30Hz *Audio synchronization and separation output can be achieved, with three audio modes of PASS, 20CH, and 5.1CH to choose from *LED indicator, when the signal source or signal end is in working state, the corresponding indicator will light up *No signal loss *Easy to install *External power supply: DC5V
Parameter
HDMI resolution: 2160P@30Hz/1080p/1080i/720p/576p/576i/480p/480i
Video color format: 24bit/deep color 30bit,36bit
Audio output: Left and right channel, optical output
Max Transmission broadband: 225MHz
Max Baud rate: 6.75Gbps
TMDS: 0.5~1.5Volts p-p
DDC: 5Volts p-p(TTL)
Input cable length: ≤15m AWG26 HDMI standard cable
Output cable length: ≤20m AWG26 HDMI standard cable
